Wiring Harness Testing System / Testing Bench
Testing Systems / Benches are customizable according to customer requirement and also dependant on the Wiring Harness
Features
Choose from our comprehensive range of test fixtures with unique functionalities to optimize your testing bench performance.
Manual Lock
Operator-controlled manual locking mechanism for test fixture positioning
Pneumatic Lock
Air-powered automatic locking system for faster testing cycles
TBO (Terminal Backout)
Specialized terminals with backout detection capability
Manual Lock/Unlock
Full manual control over both locking and unlocking operations
Pen Marking Unit
Integrated marking system for test pass/fail identification
Cutter Module
Automated cutting mechanism for wire trimming and processing
Lock Mechanism Selection
Choose between manual or pneumatic locking based on your cycle time requirements
Marking & Cutting Modules
Optional pen marking for pass/fail indication or cutter modules for wire processing
Terminal Detection
TBO (Terminal Backout) detection capability for critical wiring applications
Full Customization
Combine multiple features to create the perfect testing solution for your needs
Air Leakage Checking
Integrated leak-checking capability for reliable sealing and connectivity validation
Fixture Colour Sensor
Sensor-based colour detection support for fixture and harness verification workflows
Wiring Harness Testing & Assembly Benches
Professional testing solutions with advanced options
Customized Test Systems
Advanced testing solutions tailored to your specific requirements
HTPC with Custom Trolley
Portable testing solution with custom fixtures
Testing Station - Visual Side
With Visual Input
Testing Station - Interface Side
With Visual Input
